Microscope Objective – 7.5X Mitutoyo
Technical specifications
| Model: |
M Plan Apo 7.5X
|
| Working distance: |
In Air: 35 mm
|
| Corrected Wave Length: |
436-656 nm
|
| N.A.: |
0.21
|
| f: |
26.67 mm
|
| P.D.: |
95 mm
|
| R: |
1.3 µm
|
| FOV 1: |
ø3.2 mm
|
| FOV 2: |
0,64 x 0,85 mm
|
| Abbreviations in product table: |
N.A.: Numerical aperture
W.D.: Working distance P.D.: Parfocal distance f: Focal distance R: Resolving power D.F.: Depth of field FOV 1: Field of view when using ø24 mm eyepiece FOV 2: Field of view when using a digital camera with 1/2″ chip size |
| Functions: |
M Plan Apo for Bright Field Observation
Compatible with microscope types VMU / FS-70 / MF-U / Hyper MF-U Note: To avoid optical flare in use of coaxial illumination 1x objectives should be used togehter with polarisation unit on microscope and attached 1/4 wavelength plate. |
| Mass: |
240 g
|
€1,365.00
1 in stock
Feature highlights
- Long Working Distances
- Infinity Corrected
- Bright Field Inspection
- High-Quality Plan Apochromat Design
- Flat Image Surface over Entire Field of View
