Microscope Objective – M Plan APO NUV 100X Mitutoyo
Technical specifications
Model:
M Plan Apo
NUV 100X
NUV 100X
Functions:
Near-ultraviolet wavelength Corrected
M Plan Apo NUV for Bright Field Observation
Compatible with microscope types VMU / FS-70
Magnification:
100x
Working distance:
In Air: 11 mm
Corrected Wave Length:
355-620 nm
N.A.:
0.5
f:
2 mm
P.D.:
95 mm
R:
0.6 µm
D.F.:
1.1 μm
FOV 1:
ø0.24 mm
FOV 2:
0,05 x 0,06 mm
Abbreviations in product table:
N.A.: Numerical aperture
W.D.: Working distance
P.D.: Parfocal distance
f: Focal distance
R: Resolving power
D.F.: Depth of focus
FOV 1: Field of view when using ø24 mm eyepiece
FOV 2: Field of view when using a digital camera with 1/2″ chip size
W.D.: Working distance
P.D.: Parfocal distance
f: Focal distance
R: Resolving power
D.F.: Depth of focus
FOV 1: Field of view when using ø24 mm eyepiece
FOV 2: Field of view when using a digital camera with 1/2″ chip size
Mass:
380 g
€4,988.00
1 in stock
Description
- Suitable for Bright Field Inspection and Laser Applications
- Long Working Distance
- High Quality Plan Apochromat Design
- Wavelength correction from Visible to Near Ultraviolett (355 nm)
- High Power Type available (M Plan Apo NUV HR)
